Film Bag Stick Sachet Liquid Honey Filling Sealing Machine
Main features
1. Weight measuring, bag making, filling, sealing, cutting and bags counting can be done automatically.
2. Computer PLC control and automatic alarming function.
3. English and Chinese human-machine operation interface, it is easy to operate, a high degree of automation.
4. High sensitivity photoelectric eye color tracing, more accuracy.
5. Famous brand components, ensure the quality and durability of the machine.
Technical characteristics
1. PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing,cutting , finished in one operation.
2. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
3. Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance, belt is resistant to be worn-out.
4. External film releasing mechanism: simpler and easier installation of packing film.
5. Adjustment of bag deviation just needed to be controlled by the touch screen. Operation is very simple .
6. Close down type mechanism , defending powder into inside of machine.
Liquid Packaging Machine Specification
|
Packaging material
|
Aluminum foil composite film
|
|
Bag width
|
20 - 60mm
|
|
Bag length
|
80 - 180mm
|
|
Packing speed
|
10 - 60 bags / min
|
|
Power supply
|
220V
|
|
Whole machine power
|
2.5KW
|
|
Overall volume
|
913 * 1122 * 1961mm
|
|
Packing size
|
850 * 1230 * 2130
|
|
Packing weight
|
300KG
|
|
Lifting stroke
|
200mm
|
Product Tags:
|
|
10 - 60bags/min Automatic Liquid Filling Sealing Machine For Honey Images
|
